Using the API

Sign up for a Visodee account

To use the VisoDee API, the developer must register a free account in Visodee, Click here to register.

Terms and Conditions

Using the VisoDee API, the developer agrees at the terms and conditions describe, Read Terms and Conditions.

Postman

The explain and make example of using the API services, we will make use of the Postman service at, Click here to POSTMAN.

We encorage the developer to create a postman account and use it through the documentation examples.

Time Zone

Unless indicated, every date time information will be display with a GMT+7 time zone (Asia/Bangkok).

Service Client Request

Every service client request parameter will be describe in green tables

servicename Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
The name of the parameter	The possible values of the parameter	If the parameter is mandatory and/or optional	Extra information about the paramter

Service API Response

Every service API response parameter will be describe in red tables

servicename API Response
Parameter Key	Parameter Values	Type/Format	Remarks
The name of the parameter	The possible values of the parameter	String, Date, Number or Arrays	Extra information about the paramter
Parameters that will return an ARRAY OF DATA will be described in sub-tables of different color as example below
parameter name	-	Array	See sub-table in purple color
parametername Response
The index name of the array	The possible values	String, Date, Number or Arrays	Extra information

Next topic Basic of the API Request

Basic of the API Request

To make use of Visodee services, every requests must provide as minimun the following data:

API URL
The url to connect with the API.

Account Credentials
An UID and Secret provided to the developer when open an account with Visodee.

A Service Name
The name of the service that the developer would like to access.

Extra Service Parameters
Every service maybe will require extra information to execute the request.

Minimun requirement of a service client request parameters.

servicename Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kuid	The UID of the developer account	Mandatory	It must to be implemented in the HEADERS of the request. This field will be skip in the service information topic.
ksecret	The SECRET code of the developer account	Mandatory	It must to be implemented in the HEADERS of the request. This field will be skip in the service information topic.
kservice	The SERVICE name requested by the developer	Mandatory \| Optional	If the kservice parameter is missing the service getaccountinfo will be called
k...	Extra parameters	Mandatory \| Optional	Depending from the type of service requested may other parameters are required

Next topic Basic of the API Response

Basic of the API Response

Every response by the API to a service request is provided in Json format.

The API response will always maintain the same structure as in below table.

servicename API Response
Parameter Key	Parameter Values	Type/Format	Remarks
status	success \| error	String
service	Name of the service requested	String
message	Message in English back to the developer	String
code	success or error code number	Number
codename	success or error code string	String
date	Datetime of the request	Date yyyy-mm-dd Time hh:mm:ss	This field will be skip in the service information topic
time	Total time in seconds to process the request	Decimal Number 4 points	This field will be skip in the service information topic
data	-	Array	See sub-table in purple color
Parameter data Response
The index name of the array	The possible values	String, Date, Number or Arrays	Extra information

Next topic API Url

API Url

It consists in a secure https url connection with the Visodee api.

API Url https://api.vosodee.com/ws.php?oitcreq=blliVnBOdUczY2haZGphSy82SzVKUT09

Test the API Url on a browser

Copy and then paste the API Url inside a browser address bar and if the connection is successful you should get the following Json message.

{"status":"success","service":"welcometovisodeeapi","message":"Welcome to Visodee API. Please provide a valid account credentials to access the Visodee services.","code":"801","codename":"welcometovisodeeapi","date":"2025-01-14 09:51:55","time":0.0072,"data":[]}

Test the API Url on Postman

Login inside your account in Postman and create a new HTTP REQUEST.

Copy the API url inside the address bar.

Click SEND to forward the request to the API Visodee and should received the Json response as below.

{
	"status": "success",
	"service": "welcometovisodeeapi",
	"message": "Welcome to Visodee API. Please provide a valid account credentials to access the Visodee services.",
	"code": "801",
	"codename": "welcometovisodeeapi",
	"date": "2025-01-14 10:28:06",
	"time": 0.0022,
	"data": []
}

Next topic API Account Credentials

API Account Credentials

To access to the visodee api services the developer needs to provide the uid and secret, created during the registration process and available in the account information.

The uid and secret are mandatory and needs to be posted in the header section of the request.

servicename Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kuid	The UID of the developer account	Mandatory	It must to be implemented in the HEADERS of the request. This field will be skip in the service information topic.
ksecret	The SECRET code of the developer account	Mandatory	It must to be implemented in the HEADERS of the request. This field will be skip in the service information topic.

Test the API Account Credentials on Postman

From previous example, inside topic API url, add in the Headers area, your kuid and ksecret credentials.

Posting the request to the API, since we did not define and service name, the default service, getaccountinfo, will be called.

{
    "status": "success",
    "service": "getaccountinfo",
    "message": "Hello ACCOUNTNAME",
    "code": "803",
    "codename": "accountinfofound",
    "date": "2025-01-14 11:32:21",
    "time": 0.0084,
    "data":
			{
				"name": "ACCOUNTNAME",
				"status": "Live",
				"storeimages": "Yes",
				"credits": "471",
				"creditsexpirationdate": "2025-04-07",
				"createddatetime": "2025-01-07 12:37:10",
				"lastlogindatetime": "2025-01-14 10:51:49",
				"numberofdailyrequests": "10"
			}
}

Next topic List of Services

List of Services

Every visodee request is made by calling a service, that is passed by posting the key kservice to the api, if no service is passed the default service, getaccountinfo, is called.

List of Services

Service Name Cost Remarks

getaccountinfo [default] Free Retrieve the developer account information

analyze 1 Credit Analyze a max of 10 faces inside an image

enroll 1 Credit Enroll a single face inside an image in the system

match 1 Credit Match a max of 10 faces inside an image with the ones enrolled in the system

setgallery 1 Credit Create and manage galleries used to categories enrolled faces

getfaces Free Retrieve records of enrolled faces in the system

getgalleries Free Retrieve records of galleries in the system

removeface Free Remove a face record from the system

removegallery Free Remove a gallery record from the system

List of Services
getaccountinfo [default]	Free	Retrieve the developer account information
analyze	1 Credit	Analyze a max of 10 faces inside an image
enroll	1 Credit	Enroll a single face inside an image in the system
match	1 Credit	Match a max of 10 faces inside an image with the ones enrolled in the system
setgallery	1 Credit	Create and manage galleries used to categories enrolled faces
getfaces	Free	Retrieve records of enrolled faces in the system
getgalleries	Free	Retrieve records of galleries in the system
removeface	Free	Remove a face record from the system
removegallery	Free	Remove a gallery record from the system

Next topic Service getaccountinfo

Service getaccountinfo

The service getaccountinfo will retrieve the information of the developer account

Cost: 0 Credit [Free]

getaccountinfo Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kservice	getaccountinfo	Mandatory	This is the default service if the kservice key is not posted in the request.

getaccountinfo API Response
Parameter Key	Parameter Values	Type/Format	Remarks
status	success \| error	String
service	getaccountinfo	String
message	Hello ACCOUNTNAME \| No Account Found	String
code	805 \| 705	Number
codename	accountinfofound \| noaccountinfofound	String
data	-	Array	See sub-table in purple color
data Parameter Response
name	ACCOUNTNAME	String
status	Live \| Expired \| Suspended	String	"Live": Enable to use the API and make transactions. "Expired": Enable to use the API but cannot make transactions because credits usage date (creditsexpirationdate) is outdate. Please recharge your credits. "Suspended": Cannot use the API because the account has been suspended. Please contact support for more information.
credits	Number of Credits	Number
creditsexpirationdate	Date which credits are valid	Date yyyy-mm-dd	Indicate the date until the developer can use the credits to make transactions. Please recharge your credits to extend the date of 1 year from last top up.
createddatetime	Account date time creation	Date yyyy-mm-dd Time hh:mm:ss
lastlogindatetime	Account last date time login	Date yyyy-mm-dd Time hh:mm:ss	Last time that the developer login inside the account through Visodee website
numberofdailyrequests	Number of Free Daily Service Requests	Number	To avoid miuse of the API by the developers there is a max of 2,000 Free service requests at day

Test the service getaccountinfo on Postman

From previous example, inside topic API account credentials, select Body and form-data and add the key kservice with value getaccountinfo.

The result of posting the request to the API.

{
    "status": "success",
    "service": "getaccountinfo",
    "message": "Hello ACCOUNTNAME",
    "code": "803",
    "codename": "accountinfofound",
    "date": "2025-01-14 14:28:01",
    "time": 0.0044,
    "data":
			{
				"name": "ACCOUNTNAME",
				"status": "Live",
				"storeimages": "Yes",
				"credits": "471",
				"creditsexpirationdate": "2025-04-07",
				"createddatetime": "2025-01-07 12:37:10",
				"lastlogindatetime": "2025-01-14 12:50:41",
				"numberofdailyrequests": "19"
			}
}

Next topic Service analyze

Service analyze

The service analyze will retrieve the information of the developer account

Cost: 1 Credit

analyze Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kservice	analyze	Mandatory
kimg64	The image to post in base 64	Mandatory	Max Image Size 1Mb Extension allowed png,jpg,gif

analyze API Response
Parameter Key	Parameter Values	Type/Format	Remarks
status	success \| error	String
service	analyze	String
message	Analized [facesinimage] Face(s)	String	See facesinimage parameter below
code	820 \| 720,721	Number
codename	analyzeface \| invalidstringimagebase64, nofacesfoundinimage	String
data	-	Array	See sub-table in purple color
Parameter data Response
imgpath	The URL of the image processed	String	The image url is temporary and will be permanently deleted inside 2 hours from process. Every face detected will have following code: F(ace)[index]-S(core)[value]%
facesinimage	Number of faces detected in the image	Number	Maximum faces detected is 10
faces	-	Array	See sub-table in orange color
Parameter faces Response
index	The index of face in the array	Date yyyy-mm-dd Number	It also refers has the index Findex in the image
score	The percentage of face detection	String	The minimum score value for a face detection is 80%
faceangle	The angle of roll, picth and yaw	Array	3 indexes will are provided roll,picth and yaw
facebox	The x,y, width and height in pixel of the location of the face in the picture	Array	4 indexes will are provided x,y, width and height
age	A prediction of the person age	Number
gender	A prediction of the person gender Values female or male	String

Test the service analyze on Postman


The result of posting the request to the API.

{
    "status": "success",
    "service": "analyze",
    "message": "Analyzed 2 Face(s)",
    "code": "830",
    "codename": "analyzeface",
    "date": "2025-01-15 11:01:56",
    "time": 0.5426,
    "data":
		{
        "imgpath": "http://34.124.148.18/tmp/2025011511/IMG27_20250115110156_gGtxz.png",
        "facesinimage": 2,
        "faces": [
            {
                "index": 0,
                "score": 99.86,
                "faceangle": {
                    "roll": 21,
                    "pitch": 7,
                    "yaw": 44
                },
                "facebox": {
                    "x": 311,
                    "y": 162,
                    "w": 260,
                    "h": 263
                },
                "age": 25,
                "gender": "male"
            },
            {
                "index": 1,
                "score": 99.61,
                "faceangle": {
                    "roll": -3,
                    "pitch": -4,
                    "yaw": 28
                },
                "facebox": {
                    "x": 44,
                    "y": 226,
                    "w": 216,
                    "h": 279
                },
                "age": 19,
                "gender": "female"
            }
        ]
    }
}

Next topic Service enroll

Service enroll

The service enroll will upload a face-image associated with a label inside the system, and will register the face-label in the system database associated with the developer account.

Only 1 face needs to be contained in the image, other case the service will return an error.

Cost: 1 Credit

enroll Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kservice	enroll	Mandatory
kimg64	The image to post in base 64	Mandatory	Max Image Size 1Mb Extension allowed png,jpg,gif
klabel	Text associated with the face image	Mandatory	Max 50 Characters Characthers Range: a-z A-Z 0-9 Alphanumeric Allowed: [Space] between characters .(dot) -(dash)
kgalleryname	If empty value='Default'	Optional	Max 50 Characters Characthers Range: a-z A-Z 0-9 Alphanumeric Allowed: [Space] between characters .(dot) -(dash) Face-images are organized in galleries, so every face-image must belongs to a gallery. If the gallery name is not provided, the face-image is automatically added to a gallery called Default
kid	The record id of the face the developer wants to update	See Remarks	Optional - If not post it the system will create a new record Mandatory - If post it the system will update the record related to that id

enroll API Response
Parameter Key	Parameter Values	Type/Format	Remarks
status	success \| error	String
service	enroll	String
message	Record Face Created\|Updated ID [faceid] Label [klabel]	String
code	820 \| 720,721,722,723	Number
codename	enrollface \| invalidstringimagebase64, nofacesfoundinimage, labelismissing, enrollfailedmultiplefaces	String
data	-	Array	See sub-table in purple color
Parameter data Response
imgpath	The URL of the image processed	String	The image url is temporary and will be permanently deleted inside 2 hours from process. Every face detected will have following code: F(ace)[index]-S(core)[value]%
facesinimage	Number of faces detected in the image	Number	Maximum faces detected is 10
galleryname	The gallery name associated with the enrollment	String
faceid	The face image record id	Number
faces	-	Array	See sub-table in orange color
faces Parameter Response
index	The index of face in the array	Date yyyy-mm-dd Number	It also refers has the index Findex in the image
score	The percentage of face detection	String	The minimum score value for a face detection is 80%
faceangle	The angle of roll, picth and yaw	Array	3 indexes will are provided roll,picth and yaw
facebox	The x,y, width and height in pixel of the location of the face in the picture	Array	4 indexes will are provided x,y, width and height
age	A prediction of the person age	Number
gender	A prediction of the person gender Values female or male	String

Test the service enroll on Postman


The result of posting the request to the API.

{
    "status": "success",
    "service": "enroll",
    "message": "Record Face Created ID 11 Label Maria Angela ",
    "code": "555",
    "codename": "enrollface",
    "date": "2025-01-15 13:39:49",
    "time": 0.6274,
    "data":
		{
        "imgpath": "http://34.124.148.18/tmp/2025011513/IMG27_20250115133949_TOIui.png",
        "facesinimage": 1,
        "faces": [
            {
                "index": 0,
                "score": 99.15,
                "faceangle": {
                    "roll": -3,
                    "pitch": -4,
                    "yaw": 46
                },
                "facebox": {
                    "x": 101,
                    "y": 211,
                    "w": 417,
                    "h": 529
                },
                "age": 18,
                "gender": "female",
            }
        ],
		"galleryname": "Default",
        "faceid": "11"
    }
}

Next topic Service match

Service match

The service match will retrieve the information of the developer account

Cost: 1 Credit

match Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kservice	match	Mandatory
kimg64	The image to post in base 64	Mandatory	Max Image Size 1Mb Extension allowed png,jpg,gif
kgalleryname	If empty value or gallery not found all galleries will be used	Optional	Max 50 Characters Characthers Range: a-z A-Z 0-9 Alphanumeric Allowed: [Space] between characters .(dot) -(dash)

match API Response
Parameter Key	Parameter Values	Type/Format	Remarks
status	success \| error	String
service	match	String
message	Match Found [facesinimage] Face(s)	String	See facesinimage parameter below
code	820 \| 720,721	Number
codename	matchface \| invalidstringimagebase64, nofacesfoundinimage	String
data	-	Array	See sub-table in purple color
Parameter data Response
imgpath	The URL of the image processed	String	The image url is temporary and will be permanently deleted inside 2 hours from process. Found Faces will be squared in green Every faceNot Found Faces will be squared in red color Every face detected will have following code: F(ace)[index]-C(onfidence)[value]% Every found face will have the record id noted at the bottom
facesinimage	Number of faces detected in the image	Number	Maximum faces detected is 10
facefound	Number of faces found in the image	Number
facenotfound	Number of faces not found in the image	Number
facestocompare	Number of enrolled faces compared against the ones in the image	Number
galleryname	The gallery name associated with the match process	String	If empty will display USING ALL GALLERIES
maxdistance	The value of maximunm distance to match a face default 0.45	Decimal 2 points
faces	-	Array	See sub-table in orange color
Parameter faces Response
index	The index of face in the array	Date yyyy-mm-dd Number	It also refers has the index Findex in the image
score	The percentage of face detection	String	The minimum score value for a face detection is 80%
faceangle	The angle of roll, picth and yaw	Array	3 indexes will are provided roll,picth and yaw
facebox	The x,y, width and height in pixel of the location of the face in the picture	Array	4 indexes will are provided x,y, width and height
age	A prediction of the person age	Number
gender	A prediction of the person gender Values female or male	String
match	-	Array	See sub-table in pink color
Parameter match Response
result	found \| not found	String
id	If result is found will return the id of the best match	Number
label	If result is found will return the label of the best match	String
facesindistance	If result is found will return an array of face ids of matches under max distances	Array
bestconfidence	The overall closest face match confidence in percentage	String
closestmatch	The overall closest match id:label	String
closestdistance	The overall closest match distance	Decimal 4 points
candidates	The total number of match found candidates	Number	It is equal at the number of records in [facesindistance]

Test the service analyze on Postman


The result of posting the request to the API.

{
    "status": "success",
    "service": "match",
    "message": "Match Found 1 Faces",
    "code": "555",
    "codename": "matchface",
    "date": "2025-01-15 14:05:15",
    "time": 0.6325,
    "data":
		{
        "imgpath": "http://34.124.148.18/tmp/2025011514/IMG27_20250115140515_aHDcg.png",
        "facesinimage": 2,
        "facesfound": 1,
        "facesnotfound": 1,
        "facestocompare": 11,
        "faces": [
             {
                "index": 0,
                "score": 99.86,
                "faceangle": {
                    "roll": 21,
                    "pitch": 7,
                    "yaw": 44
                },
                "facebox": {
                    "x": 311,
                    "y": 162,
                    "w": 260,
                    "h": 263
                },
                "age": 25,
                "gender": "male",
                "match": {
						"result": "NotFound",
						"id": "",
						"label": "",
						"facesindistance": [],
						"bestconfidence": "29.76%",
						"closestmatch": "2:Justin Bee",
						"closestdistance": 0.7024,
						"candidates": 0
                }
            },
            {
                "index": 1,
                "score": 99.61,
                "faceangle": {
                    "roll": -3,
                    "pitch": -4,
                    "yaw": 28
                },
                "facebox": {
                    "x": 44,
                    "y": 226,
                    "w": 216,
                    "h": 279
                },
                "age": 19,
                "gender": "female",
                "match": {
						"result": "Found",
						"id": "11",
						"label": "Maria Angela",
						"facesindistance": {
							"11": 0.2801
						},
						"bestconfidence": "71.99%",
						"closestmatch": "11:Maria Angela",
						"closestdistance": 0.2801,
						"candidates": 1
                }
            }
        ],
        "galleryname": "USING ALL GALLERIES",
        "maxdistance": 0.45

    }
}

Next topic Service setgallery

Service setgallery

The service setgallery will manage the galleries used as a container/organizer for faces enrolled.

Cost: 1 Credit

setgallery Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kservice	setgallery	Mandatory
kgalleryname	If empty value='Default'	Optional	Max 50 Characters Characthers Range: a-z A-Z 0-9 Alphanumeric Allowed: [Space] between characters .(dot) -(dash)
kid	The record id of the gallery the developer wants to update	See Remarks	Optional - If not post it the system will create a new record Mandatory - If post it the system will update the record related to that id

setgallery API Response
Parameter Key	Parameter Values	Type/Format	Remarks
status	success \| error	String
service	setgallery	String
message	Gallery [name] Created/Updated ID [id]	String
code	805 \| 705	Number
codename	gallerycreated,galleryupdated	String
data	-	Array	See sub-table in purple color
data Parameter Response
id	Gallery record id	Number
name	Gallery name	String
datecreated	Datetime of record creation	Date yyyy-mm-dd Time hh:mm:ss

Test the service setgallery on Postman

From previous example, inside topic API account credentials, select Body and form-data and add the key kservice with value setgallery and kgalleryname as example 'accounting department'.

The result of posting the request to the API.

{
    "status": "success",
    "service": "setgallery",
    "message": "Gallery accounting department Created ID 2",
    "code": "821",
    "codename": "gallerycreated",
    "date": "2025-01-15 14:54:36",
    "time": 0.0618,
    "data":
			{
				"id": "2",
				"name": "accounting department",
				"datecreated": "2025-01-15 14:54:36"
			}
}

Next topic Service getfaces

Service getfaces

The service getfaces will retrieve the records of the faces enrolled.

Cost: 0 Credit [Free]

getfaces Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kservice	getfaces	Mandatory
kpage	Default is 0	Optional	Retrieving the records will use a paging system, where the developer will need to define the page, so the page where start to select records, and paging, number of record per page
kpaging	Number of records to return Value between 1-100 Default is 50	Optional
kid	Search by record id	Optional	Must be a number
klabel	Search by face label	Optional	Max 50 Characters Characthers Range: a-z A-Z 0-9 Alphanumeric Allowed: [Space] between characters .(dot) -(dash)
kgalleryname	Search by gallery name	Optional	Max 50 Characters Characthers Range: a-z A-Z 0-9 Alphanumeric Allowed: [Space] between characters .(dot) -(dash)

getfaces API Response
Parameter Key	Parameter Values	Type/Format	Remarks
status	success \| error	String
service	getfaces	String
message	Found [numberrecords] Records of [totalrecords],No Record Found	String
code	805 \| 705	Number
codename	getfacesrecordfound,getfacesnorecordfound	String
data	-	Array	See sub-table in purple color
data Parameter Response
numberrecords	Number of record returned	Number
totalrecords	Number of total record for that search	Number
page	The return search page	Number
paging	The request number of records by page	Number
records	-	Array	See sub-table in orange color
records Parameter Response
id	Face record id	Number
label	Face label	String
galleryname	The gallery name associated with the face	String
imgpath	A temporary URL of the image enrolled	String	The image url is temporary and will be permanently deleted inside 2 hours from process

Test the service getfaces on Postman

From previous example, inside topic API account credentials, select Body and form-data and add the key kservice with value getfaces, kpage(optional) as example 1 and kpaging(optional) as example 3

The result of posting the request to the API.

{
    "status": "success",
    "service": "getfaces",
    "message": "Found 3 Records of 11",
    "code": "745",
    "codename": "getfacesrecordfound",
    "date": "2025-01-16 10:43:11",
    "time": 0.0126,
    "data":
			{
				"numberrecords": 3,
				"totalrecords": "11",
				"page": 1,
				"paging": 3,
				"records": [
					{
						"id": "5",
						"label": "Mau",
						"age": "35",
						"gender": "male",
						"datecreated": "2025-01-07 13:47:04",
						"galleryname": "Default",
						"imgpath": "http://34.124.148.18/vsdee/temps/files/IMG27_20250107134703_FR1BA-20423.jpg"
					},
					{
						"id": "10",
						"label": "Karim",
						"age": "64",
						"gender": "male",
						"datecreated": "2025-01-14 14:23:48",
						"galleryname": "accounting department",
						"imgpath": "http://34.124.148.18/vsdee/temps/files/IMG27_20250114142348_X4DE4-20434.jpg"
					},
					{
						"id": "11",
						"label": "Maria Angela",
						"age": "18",
						"gender": "female",
						"datecreated": "2025-01-15 13:39:49",
						"galleryname": "Default",
						"imgpath": "http://34.124.148.18/vsdee/temps/files/IMG27_20250115133949_TOIui-20435.jpg"
					}
				]
			}
}

Next topic Service getgalleries

Service getgalleries

The service getgalleries will retrieve the records of the galleries.

Cost: 0 Credit [Free]

getgalleries Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kservice	getgalleries	Mandatory
kpage	Default is 0	Optional	Retrieving the records will use a paging system, where the developer will need to define the page, so the page where start to select records, and paging, number of record per page
kpaging	Number of records to return Value between 1-100 Default is 50	Optional
kid	Search by record id	Optional	Must be a number
klabel	Search by gallery name	Optional	Max 50 Characters Characthers Range: a-z A-Z 0-9 Alphanumeric Allowed: [Space] between characters .(dot) -(dash)

getgalleries API Response
Parameter Key	Parameter Values	Type/Format	Remarks
status	success \| error	String
service	getgalleries	String
message	Found [numberrecords] Records of [totalrecords],No Record Found	String
code	805 \| 705	Number
codename	getgalleriesrecordfound, getgalleriesnorecordfound	String
data	-	Array	See sub-table in purple color
data Parameter Response
numberrecords	Number of record returned	Number
totalrecords	Number of total record for that search	Number
page	The return search page	Number
paging	The request number of records by page	Number
records	-	Array	See sub-table in orange color
records Parameter Response
id	Face record id	Number
label	Gallery name	String
totalfaces	The number of faces enrolled inside the gallery	Number

Test the service getgalleries on Postman

From previous example, inside topic API account credentials, select Body and form-data and add the key kservice with value getgalleries, kpage(optional) as example 1 and kpaging(optional) as example 3

The result of posting the request to the API.

{
    "status": "success",
    "service": "getgalleries",
    "message": "Found 2 Records of 2",
    "code": "745",
    "codename": "getgalleriesrecordfound",
    "date": "2025-01-16 11:22:45",
    "time": 0.0087,
    "data":
			{
				"numberrecords": 2,
				"totalrecords": "2",
				"page": 0,
				"paging": 50,
				"records": [
					{
						"id": "1",
						"label": "Default",
						"totalfaces": "9"
					},
					{
						"id": "2",
						"label": "accounting department",
						"totalfaces": "2"
					}
						]
					}
}

Next topic Service removeface

Service removeface

The service removeface will remove a face record by id

Beware that all the records related to the face record will be removed as example Time Attendance

Cost: 0 Credit [Free]

removeface Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kservice	removeface	Mandatory
kid	Remove record id	Mandatory	Must be a number

removeface API Response
Parameter Key	Parameter Values	Type/Format	Remarks
status	success \| error	String
service	removeface	String
message	Face id [id] label [label] has been deleted	String
code	805 \| 705	Number
codename	facehasbeendeleted	String
data	-	Array	See sub-table in purple color
data Parameter Response
id	The id of the record deleted	Number
label	The label of the record deleted	String

Test the service removeface on Postman

From previous example, inside topic API account credentials, select Body and form-data and add the key kservice with value removeface, kid as example 10

The result of posting the request to the API.

{
    "status": "success",
    "service": "removeface",
    "message": "Face id 10 label Karim has been deleted",
    "code": "855",
    "codename": "facehasbeendeleted",
    "date": "2025-01-16 12:21:33",
    "time": 0.0733,
    "data":
		{
			"id": "10",
			"label": "Karim"
		}
}

Next topic Service removegallery

Service removegallery

The service removegallery will remove a gallery record by id

Beware that the gallery does not need to contain any face enrolled to be successfully removed

Cost: 0 Credit [Free]

removegallery Client Request
Parameter Key	Parameter Values	Mandatory \| Optional	Remarks
kservice	removegallery	Mandatory
kid	Remove record id	Mandatory	Must be a number

removegallery API Response
Parameter Key	Parameter Values	Type/Format	Remarks
status	success \| error	String
service	removegallery	String
message	Gallery id [id] label [label] has been deleted	String
code	805 \| 705	Number
codename	galleryhasbeendeleted	String
data	-	Array	See sub-table in purple color
data Parameter Response
id	The id of the record deleted	Number
label	The label of the record deleted	String

Test the service removegallery on Postman

From previous example, inside topic API account credentials, select Body and form-data and add the key kservice with value removegallery, kid as example 2

The result of posting the request to the API.

{
    "status": "success",
    "service": "removegallery",
    "message": "Gallery id 2 label accounting department has been deleted",
    "code": "855",
    "codename": "galleryhasbeendeleted",
    "date": "2025-01-16 12:36:48",
    "time": 0.0547,
    "data":
		{
			"id": "2",
			"label": "accounting department"
		}
}

Next topic Codes by Service status

Service Codes by Service status

Codes by Service status
Service Name	Status	Code	Codename	Message	Remarks
Not Available	success	801	welcometovisodeeapi	Welcome to Visodee API. Please provide a valid account credentials to access the Visodee services	When test the API url
Any Service	error	701	invalidaccountcredentials	Invalid Account Credentials. Please provide a valid UID and Secret.	Authorization access process
Any Service	error	702	accounthasbeensuspended	Account has been Suspended. Please contact support for more information.	Authorization access process

Next topic Examples in PHP

Service Examples in PHP

The following PHP code examples will test 2 services, getaccountinfo and setgallery

Please replace ACCOUNTUID and ACCOUNTSECRET with your account information

Example service getaccountinfo:


					<?php

						//API url
						$url = "http://34.124.148.18/vsdee//ws.php?oitcreq=blliVnBOdUczY2haZGphSy82SzVKUT09";

						//Account Credentials in the headers
						$a_headers = [];
						$a_headers[] = "Content-Type:multipart/form-data";
						$a_headers[] = "kuid:ACCOUNTUID";
						$a_headers[] = "ksecret:ACCOUNTSECRET";

						//Service parameters
						$apostdata = [];
						$apostdata["kservice"] = "getaccountinfo";

						$ch = curl_init();

						curl_setopt($ch, CURLOPT_URL,$url);
						curl_setopt($ch, CURLOPT_POST, true);
						curl_setopt($ch, CURLOPT_POSTFIELDS,$apostdata);
						curl_setopt($ch, CURLOPT_HTTPHEADER, $aheaders);

						curl_setopt($ch, CURLOPT_CONNECTTIMEOUT, 0);
						curl_setopt($ch, CURLOPT_TIMEOUT, 10);

						curl_setopt($ch, CURLOPT_SSL_VERIFYHOST, 0);
						curl_setopt($ch, CURLOPT_SSL_VERIFYPEER, 0);

						//Server respons
						curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);

						$server_output = curl_exec($ch);

						$errstr=null;
						$errno = null;

						if(curl_errno($ch))
						{
							$curl_errno = curl_errno($ch);
							$curl_errormsg = curl_error($ch);

							$a_result = array(
							"curlstatus"=>"error",
							"data"=>"No ".$curl_errno.":".$curl_errormsg,
							);
						}
						else
						{
							$a_result = array(
							"curlstatus"=>"success",
							"data"=>$server_output,
							);
						}

						curl_close ($ch);

						echo "<pre>";
						echo print_r($a_result,true);
						echo "</pre>";

					?>

Example service setgallery:


					<?php

						//API url
						$url = "http://34.124.148.18/vsdee//ws.php?oitcreq=blliVnBOdUczY2haZGphSy82SzVKUT09";

						//Account Credentials in the headers
						$a_headers = [];
						$a_headers[] = "Content-Type:multipart/form-data";
						$a_headers[] = "kuid:ACCOUNTUID";
						$a_headers[] = "ksecret:ACCOUNTSECRET";

						//Service parameters
						$apostdata = [];
						$apostdata["kservice"] = "setgallery";
						$apostdata["kgalleryname"] = "Private";

						$ch = curl_init();

						curl_setopt($ch, CURLOPT_URL,$url);
						curl_setopt($ch, CURLOPT_POST, true);
						curl_setopt($ch, CURLOPT_POSTFIELDS,$apostdata);
						curl_setopt($ch, CURLOPT_HTTPHEADER, $aheaders);

						curl_setopt($ch, CURLOPT_CONNECTTIMEOUT, 0);
						curl_setopt($ch, CURLOPT_TIMEOUT, 10);

						curl_setopt($ch, CURLOPT_SSL_VERIFYHOST, 0);
						curl_setopt($ch, CURLOPT_SSL_VERIFYPEER, 0);

						// Receive server response ...
						curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);

						$server_output = curl_exec($ch);

						$errstr=null;
						$errno = null;

						if(curl_errno($ch))
						{
							$curl_errno = curl_errno($ch);
							$curl_errormsg = curl_error($ch);

							$a_result = array(
							"curlstatus"=>"error",
							"data"=>"No ".$curl_errno.":".$curl_errormsg,
							);
						}
						else
						{
							$a_result = array(
							"curlstatus"=>"success",
							"data"=>$server_output,
							);
						}

						curl_close ($ch);

						echo "<pre>";
						echo print_r($a_result,true);
						echo "</pre>";

					?>

Next topic About the API

Service About the API

Version: 1.0

Date: 2025-01-06

Authors: MauC & TawS

List of Services
Service Name	Cost	Remarks
getaccountinfo [default]	Free	Retrieve the developer account information
analyze	1 Credit	Analyze a max of 10 faces inside an image
enroll	1 Credit	Enroll a single face inside an image in the system
match	1 Credit	Match a max of 10 faces inside an image with the ones enrolled in the system
setgallery	1 Credit	Create and manage galleries used to categories enrolled faces
getfaces	Free	Retrieve records of enrolled faces in the system
getgalleries	Free	Retrieve records of galleries in the system
removeface	Free	Remove a face record from the system
removegallery	Free	Remove a gallery record from the system

API Documents

Using the API

Basic of the API Request

Basic of the API Response

API Url

API Account Credentials

List of Services

Service getaccountinfo

Service analyze

Service enroll

Service match

Service setgallery

Service getfaces

Service getgalleries

Service removeface

Service removegallery

Service Codes by Service status

Service Examples in PHP

Service About the API
